Iridium Pilot®

Iridium Pilot is the only reliable truly global connection for broadband voice and data maritime communications – delivering exceptional performance, durability and value, everywhere on the planet.



Tech Specs & Features



• Pole-to-pole global coverage

• Simultaneous voice and high-speed IP data

• Solid state - no moving parts

• Global Service Program (includes 5-year limited warranty*)

• Easy to install



* One-year limited warranty on accessories

Above Decks Equipment (ADE)



• Height: 8.0 in (203 mm)

• Diameter: 22.44 in (570 mm)

• Weight: 27.5 lb (12.5 kg)

• Antenna type: Six dual element azimuth and one zenith element array

• Steering: Electronically switched and phase steered, horizon to horizon



Below Decks Equipment (BDE)



• Height: 7.78 in (200 mm)

• Width: 9.84 in (250 mm)

• Depth: 2.17 in (55 mm)

• Weight: 2.98 lb (1.35 kg)



Data



• Up to 134 kbps bidirectional with Iridium OpenPort® broadband service



Telephony



• Three independent voice lines

• Configurable for captain, bridge, or crew calling
